Description

Product selling point

 Infra-red LEDs for night-time vision, Effective night vision range 15m

 380 TV lines clear picture display,Weather-proof design for outdoor usage,Alloyed shell

 channel available to Channel scan and channel skip for multi-camera usage

 Built-in microphone for audio monitoring 7 inch TFT LCD 2.4GHz 4-Channels Wireless AV Color Monitor.Receiver inside easy installation

 PAL/NTSC System.

 Remote Control with Full Functions.On screen display (OSD) menu

Parameter list

 Transmission Frequency

ISM 2,400MHz~ 2,483MHz ,4CH*

 Modulation Mode

FM

 Antenna TypeCamera

 Omni; Receiver Hidden

 Unobstructed Effective Range

100m(Without Block)

 Operating Temperature

0°C~ +50°C / +14°F~ +122°F

 Storage Temperature

-20°C ~ +60°C / -4°F ~ +140°F

 Operating Humidity

85%RH

Camera

 Imaging Sensor Type

CMOS

 CMOS Total Pixels

628×582(PAL)/ 510×492(NTSC)

 Horizontal Resolution

380 TV Lines

 View Angle

 PAL62°;   NTSC46°

 Minimum Illumination

5.0 Lux / F1.2 & 0 Lux(IR ON)

 Transmission Power

80mW

 Power Supply

DC 5V 1000mA

 Night Vision Range

15m

 Consumption Current

80 mA & 200mA(IR ON)

 Dimensions (WxDxH)

¢57mm*67mm

 Weight

190g

Receiver

 Receiving Sensitivity

≤-85dBm

 LCD Type

TFT

 LCD Screen Size

7"

 Dot Pitch

0.1025mm×0.163mm

 View Angle(U/D/L/R)

10°/ 30°/ 45°/ 45°(Min.)

 Brightness

250 cd/m3

 Contrast Ratio

1900-1-6  60100

 Interface

Alternated Video Signal

 Light Source

CCFL*

 Power Supply

DC 12V 2A

 Video Output Signal Level

1Vp-p@75 Ohm,S/N>38dB

 Audio Output Signal Level

1Vp-p@600 Ohm

 Dimensions (WxDxH)

190mm*140mm*20mm

 Weight

425g
